Sheds
Tool Shed Tall
Ranch styling with the wall height added back
The most popular ranch-style building in the line. Same clean single-ridge roof as the Tool Shed, with taller sidewalls — which is the difference between a building you store things in and one you can work in.
Worth knowing
The extra wall height is what makes shelving, pegboard and a bench worth installing. It also covers the full size range up to 12' x 32', so it scales from a backyard shed to something closer to a workshop.
Features
- Taller sidewalls
- Ranch-style roof
- Full size range
- Eight floor plans
Common uses
- Workshop
- Storage with wall shelving
- Equipment storage
- Hobby space
Available sizes
| Size | Footprint |
|---|---|
| 8' × 12' | 96 sq ft |
| 10' × 12' | 120 sq ft |
| 10' × 14' | 140 sq ft |
| 10' × 16' | 160 sq ft |
| 10' × 20' | 200 sq ft |
| 12' × 16' | 192 sq ft |
| 12' × 20' | 240 sq ft |
| 12' × 24' | 288 sq ft |
| 12' × 28' | 336 sq ft |
| 12' × 32' | 384 sq ft |
Floor plans
The floor plan sets where the doors and windows go. This model is offered in 8 plans — the same building, laid out differently. Tell us how you will approach it and what goes inside, and the right one is usually obvious.
More of the Tool Shed Tall
How it is built
Floor
- Treated skids and joists on 16" centers, rated for ground contact
- 4x6 notched floor skids — two on 8' wide buildings, four on 10' and 12' wide
- 5/8" LP ProStruct treated floor decking with interlocking SmartFinish
Walls
- LP SmartSide engineered wood siding and trim, treated against water and insects
- 2x4 studs on 16" centers
- Metal hurricane straps tying wall framing to rafters, rated to 160 mph
Roof
- 2x4 rafters joined with steel plates
- 7/16" OSB roof decking
- Aluminum drip edge protecting decking and eaves
Doors
- 6" heavy-duty zinc-plated hinges and handle
- Adjustable tension rods to stop the doors sagging
- Aluminum threshold protecting the floor edge
